6' ViewPack® Tie-back Energy Absorbing Lanyard, Single-leg with Aluminum Connectors

SKU:

825623A

UPC:

category tier 2:

Energy Absorbing Lanyards

filter - anchorage connector:

Rebar Hook

performance 5 detail:

1,800 lb

material 4 header:

D-ring

filter - brand:

ViewPack®

filter - connector material:

Aluminum Alloy

document name 2:

Declaration of Conformity

material 1 detail:

Polyester; 5,000 lb min. static strength

performance 7 header:

OSHA User Capacity

performance 1 header:

Static Strength

material 4 detail:

Plated alloy steel; 5,000 lb min. static strength

3rd bullet:

Energy absorber features patented ViewPack® cover with inspection window

material 2 detail:

Polyester tear-away

5th bullet:

Includes aluminum alloy snap hooks for harness attachment and D-ring anchorage connection

1st bullet:

Constructed with jacketed double-layer polyester webbing for added strength and abrasion resistance

performance 6 detail:

130 to 310 lb max.

4th bullet:

ViewPack® cover also features WrapPack label protection

performance 3 header:

Max. Arrest Distance

performance 6 header:

ANSI User Capacity

document file 2:

declarations_of_conformity/C0917070a_DOC.pdf

filter - osha:

OSHA Compliant

performance 2 header:

ANSI Lanyard Class

filter - ansi:

ANSI Compliant

material 1 header:

Webbing

performance 7 detail:

130 to 310 lb max.

filter - lanyard material:

Jacketed Polyester Webbing

filter - harness attachment:

Snap Hook

family group:

ViewPack® Lanyard

performance 1 detail:

5,000 lb min.

document name 1:

Instruction Manual

product type:

Single-leg Tie-back

performance 3 detail:

48"

document file 1:

instruction_manuals/MSAL01ALX_Rev_A.pdf

relevant standards 2:

OSHA 1926.502 and 1910.66

material 3 header:

Connectors

performance 4 detail:

900 lb

performance 2 detail:

6' free fall

relevant standards 1:

ANSI Z359.13-2013

category tier 3:

ViewPack®

other items you may need:

7008B, 7372, 72706SB1

performance 4 header:

Avg. Arrest Force

material 2 header:

Energy Absorber

6th bullet:

Complies with ANSI Z359.13-2013

material 3 detail:

Aluminum alloy; 5,000 lb min. static strength with 3,600 lb gate strength

filter - leg type:

Fixed Length

descriptor 1:

6' with aluminum connectors

performance 5 header:

Max. Arrest Force

filter - configuration:

Single-leg

2nd bullet:

Features Tie-back D-ring for wrap-around anchoring and eliminates the need for a separate tie-off anchor point.

similar solutions:

8241, 82562, 8260732D
